Description
Lightweight, powerful, high-capacity battery and modern frame design. The all-new AMFlow PL Carbon is an advanced electric mountain bike with unbeatable specification numbers to put a smile on any demanding e-MTB riders face.
The entry level PL Carbon model gets you unrivalled spec for the money, the exact same frame and drive system as the Pro model with renown high-spec components from SRAM and Fox. The PL Carbon comes with the 800wh battery for maximum ride time.
At the core of the AmFlow PL Carbon is the DJI Avinox drive system, this seamlessly integrated motor has incredible power-to-weight and pushes out an enormous 850w peak and 105nm of torque while only coming in at 2.52kg. This revolutionary motor is paired with a 800wh, 157km range (3.74kg) battery, which is cleverly hidden in the bikes downtube.
As well as the expected Eco, Trail and Turbo, the DJI Avinox Drive System also features a specialised Auto mode, which adapts assistance in real-time based on road conditions and riding position. Once enabled, Auto mode empowers users to tackle a wide variety of terrain types and gradients without having to switch modes. On top of this there is a walk assist mode for pushing the bike to the uplift and also a BOOST mode that gives a short burst of huge power (120nm, 1000w) for 30 seconds should you need to get over a particularly tricky piece of terrain. The Trail mode is more than equivalent to many other brands' boost mode.
Ordering Info
Demand is very high for the PL Carbon and any bikes that come into free stock usually sell immediately. We can take a refundable deposit to secure place in the queue. If the bike does not show as IN STOCK then there will be some lead time. Current lead times are:
- Medium: Mid May
- Large: Early May
- XL: Late April
- XXL: Late May
We can upgrade the fork on the PL Carbon to the Fox Float Factory GRIP2 in orange for +£350 which is a mega deal. If you'd like more information on this or any other upgrades or part swaps please do contact us.
Key Features -
- Light-weight carbon frame (approx 2.27kg)
- DJI 105nm/850w drive system
- Large capacity battery - 800wh
- 160mm front, 150mm rear travel
- 29" wheel (rear can be swapped to 27.5")
- 5 power modes inc walk assist
- Built-in display with smartphone connectivity
The official Amflow PL frame bag is also available to order - HERE
FRAME -
The AmFlow PL's frame is ultra-lightweight and designed to be balanced and agile, as well as to fully integrate the electric technology while maintaining the ride feel of a standard bike. 150mm of rear travel uses an advanced four-bar linkage structure that significantly reduces pedal kickback while greatly improving pedalling efficiency, ensuring that every stroke counts.
DJI Avinox Drive System -
Designed and manufactured by DJI, the Avinox Drive Unit is a huge leap forward for elecrtric mountain bike motor technology, featuring a compound planetary gearset with an industry-leading power-to-size ratio.
The durable, high-strength polymer material inside the Drive Unit effectively suppresses noise during high-speed gearbox operation. With multiple precision sensors built-in, combined with advanced DJI algorithms, it provides a strong, smooth assistance for a wide range of scenarios and conditions.
Specifications::PL Carbon
-
Discipline: Enduro/All-Mountain
-
Material: Carbon
-
Front Travel: 160mm
-
Rear Travel: 150mm
-
Wheel Size: 29"
-
Warranty: 5 Years (frame)
Drive System - Avinox M1 Drive Unit: 105 N·m, 2-inch OLED Control Display
Rear Shock - FOX Float Performance, Trunnion (185×55mm), custom tune, EVOL Air sleeve, 2-position lever
Fork - FOX 36 Performance, 160mm travel, GRIP Damper, 15×110mm, 44mm rake
Derailleur - SRAM GX Eagle 12-speed
Crankset - DJI Avinox SL Crank (M/L: 155mm; XL/XXL: 160mm)
Shifter - SRAM GX Eagle Trigger Shifter｜Single Click
Cassette - SRAM PG-1230, 11-50T
Chain - SRAM NX Eagle
Brakes - Magura MT5 hydraulic disc brake, HC lever, 4-piston caliper w/ Shiftmix 3, 203mm MDR-C Rotor (front and rear)
Wheels - Amflow HMA-30, Alloy, 29'', 30mm internal width, 32H, tubeless ready
Tyres - Front: Maxxis Assegai MaxxTerra 29×2.5" WT 3C EXO E-25 TLR, Rear: Maxxis Dissector MaxxTerra 29×2.4" WT 3C EXO+ E-25 TLR
Handlebar - Amflow Enduro Alloy Handlebar
Grips - Amflow Enduro Grips
Stem - Amflow Enduro Stem, One-piece CNC
Saddle - Selle Royal SRX Plus
Seatpost -KS Rage-i
Accessories - Quick Start Guide, Torque Wrench, Shock Pump, Front and Rear lights
